Description
The 2300MHz-2550MHz AMPS (35W) S-band RF Power Amplifier is specifically designed for applications in the S-band frequency range. With a frequency range from 2300MHz to 2550MHz, it provides a power output of 35 watts, making it suitable for amplifying high-power RF signals. This amplifier finds wide application in S-band communication systems, including satellite communication, radar systems, and wireless communication.
Key Features:
The 2300MHz-2550MHz AMPS (35W) S-band RF Power Amplifier plays a crucial role in S-band communication systems, delivering efficient and reliable signal amplification for various applications.
Specification
SPECIFICATIONS @ +12VDC, 25°C, 50 Ω System
| Parameter | Symbol | Min | Typ | Max | Unit |
| Operating Frequency | BW | 2300 | 2550 | MHz | |
| Module Output peak Power | Pout | 35 | W | ||
| Input Power for Nominal Output | Pin | 8 | 13 | dBm | |
| Pulse width | 200 | us | |||
| Duty cycle | ≤10% | ||||
| Rise time | ≤500 | ns | |||
| Pulse waveform drop(25℃) | ≤0.5 | dB | |||
| Input VSWR | ≤2 | ||||
| Harmonic Signals | H | ≤-35 | dBc | ||
| Spurious Signals | Spur | ≤-55 | dBc | ||
| Under IN alarm | ≤5 | dBm | |||
| Under OUT alarm | ≤25 | W | |||
| Operating Voltage | VDD | +12,-5 | Volt |
Applications
Wireless Communication Systems: RF power amplifiers are used to enhance the power of wireless signals in various communication systems, including mobile communication base stations, wireless LAN (Wi-Fi), cellular networks, and cellular phones. They improve signal transmission distance and coverage, ensuring communication quality.
Radar Systems: In radar systems, RF power amplifiers are utilized to boost the power of radar signals, including civilian radar, military radar, aviation radar, weather radar, etc. They enhance radar system detection range, target resolution, and anti-interference capability.
Broadcasting and Television: RF power amplifiers are employed to increase the power of broadcasting signals, including radio broadcasting stations, television broadcasting, satellite broadcasting, etc. They improve signal coverage and reception quality in broadcasting and television applications.
Satellite Communication: In satellite communication systems, RF power amplifiers are used to amplify satellite signals, including satellite ground stations, satellite communication equipment, satellite phones, etc. They enhance the reliability and stability of satellite communication.
Medical Equipment: RF power amplifiers are used to boost the signal power of medical equipment, such as medical ultrasound devices, medical magnetic resonance imaging (MRI) equipment, etc. They improve diagnostic accuracy and efficiency in medical applications.
Scientific Research: In scientific research fields, RF power amplifiers are utilized in various experimental and observational equipment, such as astronomical telescopes, particle accelerators, electromagnetic spectrometers, etc. They enhance data acquisition capabilities and accuracy in scientific research.
In summary, RF power amplifiers find significant applications in modern communication, broadcasting, radar, medical, and scientific research fields, providing reliable signal amplification solutions for various RF signal processing needs
